Product parameters
system |
main processor | Hi3536DV100 |
operating system | embedded LINUX operating system | |
System resources | Simultaneous multi-channel real-time video recording, multi-channel real-time playback, multi-channel multi-person network operation | |
The 16-bit true color graphical menu operation interface, which supports mouse operations. | ||
screen | 1/4/8/9/16 | |
Video |
The 16-bit true color graphical menu operation interface, which supports mouse operations. | |
screen | 1/4/8/9/16 Video Access Mode 16 5M(15fps)/16 1080P | |
Access bandwidth | 64Mbps | |
The forwarding bandwidth | 36Mbp | |
image decoding | H.265/H.264 | |
monitoring quality | Max 2560*1440 | |
playback quality | 5M/1080P | |
decoding capability | 1 5M/2 1080P | |
video playback | video recording method | Manually,> Alarm, and dynamic detection. |
Local playback | 1 5M/2 1080P | |
video inquiry | Point-in-time search, calendar search, event search, and channel search | |
video preservation | local hard disk, network | |
The backup method | Network backup, USB mobile hard disk, USB burn, SATA burn | |
API |
Video output | One HDMI HD output and one VGA output |
audio I/O | 0/1(3.5MM) | |
Network interface | 1 RJ45 10M/100M adaptive Ethernet port | |
USB interface | Two USB2.0 interfaces (one USB extension interface is reserved) | |
Hard Disk Interface | One SATA API (each supports a maximum of 8T.) | |
ONVIF | support | |
power supply | 12V/2A | |
power consumption | <10W (excluding hard disk) | |
working environment | temperature: 0 ℃-+55 ℃, humidity: 10%-90% RH, atmospheric pressure: 86kpa-106kpa | |
size | 118mm * 46mm | |
weight | approximately 44g |
